Understanding NEMA Ratings: A Comprehensive Overview

NEMA is the signifier used by the National Electrical Manufacturers Association, which tends to rule the industrial standards for using electrical enclosures and items.

Besides, NEMA provides every industry device with a suitable rating to shield it from any personal gain to the harmful contents, and any extra type-dependent chosen environmental instances. There can be countless environmental instances against which the rating is relevant to offering the gadget’s ultimate defense.

If you’re new to all this, you may be asking what the NEMA rating is. The post below breaks it down so you can understand better.

Is NEMA the Same As IP?

No. NEMA is an American standard, while IP is a European standard so there’s no NEMA rating vs IP rating. Specialists developed NEMA to form the technical measures for producing electrical equipment and medical imaging apparatus.

NEMA works to set industry levels for:

• Environment

• Safety

• Interoperability

• Creativity

• Market improvement of our industry

Though the NEMA bureau supervises different responsibilities in electrical manufacturing production, most people closely associate them with NEMA classifications and the kind of enclosure an electrical piece or a flat cord power strip are constructed with.

Similarities and Differences Between IP Rating and NEMA Rating

Here’s where the resemblance with IP ratings starts. IP stands for International Protection. However, individuals almost always interpret it as Ingress Protection since the classification structure indicates the degree of defense from the entry of water and dust.

NEMA classifications and IP gradings define shielding levels against substances like dust and water. But they use varying test parameters and techniques to determine their enclosure types. NEMA utilizes NEMA 250 to Nema5-15r switches, and IP uses standard 60529.

Like the IP classification system, the NEMA grading structure permits us to spot an enclosure to suit the surroundings where a flat plug extension cord must be fixed.

Moving on, experts use NEMA ratings specifically for enclosures. However, professionals use IP ratings for all types of appliances.

• The IP classification formation utilizes two numbers, IP66, where the first digit shows the degree of dust shielding. In this case, the six means the enclosure is defended from dust.
• The second number shows the degree of water entry shielding, with six meaning the enclosure is protected from heavy water jet spray. There’s no direct change between NEMA ratings and IP ratings. However, the degree of defense they offer is equivalent.

Therefore, we can say that the NEMA grading equal to IP66 is NEMA four or 4X, with the four X offering an extra degree of shielding from corrosion.

NEMA Grading Levels

While NEMA ratings for non-hazardous locations go from one through to six and eleven through to thirteen, NEMA ratings for hazardous areas go from seven to ten.

NEMA Types for Non-Dangerous Area

• Type 1 NEMA- it’s most frequently used to specify and spot the protection for commercial indoor applications like junctions, switches, and utility boxes like the 30 amp extension

• Type 2 NEMA- it’s similar to type 1 but comes with an extra drip shield used mainly in cooling and laundry rooms.

• Type 3R/3RX NEMA protects against weather hazards, falling dirt, and windblown dust.

• Type 3/3X NEMA- dust-tight, rain-tight, and sleet-tight- are made for outdoor and indoor use.

• Type 3S/3SX NEMA benefits from a similar shielding as NEMA 3. However, it offers protection when ice builds on the enclosure and will stay functional when covered in ice. The 3SX adds defense against corrosion.

• Type 4/4X NEMA provides the same shielding as NEMA 3 enclosure but with extra protection against water entry and hose-directed water.

• Type 5 NEMA can handle light splashing but can’t be immersed for a long time.

• Type 6/6P NEMA offers extra protection from short-term water submersion to a chosen depth. A 6P section means you can immerse in the chamber for a long time.

• Type 11 NEMA are corrosion-resistant and offer to shield even when immersed in lubricant.

• Type 12 NEMA- NEMA 12 and 12K enclosures are rust-resistant and shield from splashing and dripping water.

• Type 13 NEMA offers extra protection against sprayed or dripping coolants and oils.

NEMA Types for Dangerous Areas

• NEMA 7/9 rating

• NEMA 9 rating

• Type 9 NEMA

• NEMA 7 vs NEMA 4x

Regardless of the production you deal with, it’s vital to check its NEMA rating before fixing it with your other appliances if you utilize any electrical apparatus. You can have countless reasons to do so, among which are:

• The ratings assist the user in confirming if the electrical enclosures have good durability.

• It offers adequate details concerning the electrical equipment’s operational standards, stability, and security.

• The NEMA grading not only bears crucial details but also assists the user in understanding the mechanism correctly.

• If you’ve been seeking the ideal instrument for industrial use, such grading will assist you in narrowing down the search outcome as per the kind of surrounding in which you wish to use the component.

Conclusion

Ultimately, NEMA ratings are crucial for your and your property’s safety. That’s why you must consider learning all there is to know about them before settling for a specific enclosure. Granted, it might not be easy to adjust if you’re learning about them now, but you’ll know all about them with time and patience.
